GMP Standard- Aseptic Laminar Air Pass through cabinets

Aseptic laminar air pass through cabinets have the features of high cleanliness class and sterilization function, significantly maintain the high cleanliness class within the clean environment, usually used by medicine industries.

Get A Quote

浏览次数：

Product Features

Product Features:

● Airtight: Technical sealing strips made by dispensing machine, once molding, door handle is press-buckle type
● Easy-cleaning: Interior coved corners construction, easily wipe up
● Classy appearance: Double glazed windows, smooth and bright

Standard Drawing:

Specifications:

Size WDH	Outside 860x680x1250 Inside 600x600x600	1060x880x1450 800x800x800
Main Material	Stainless Steel SUS304: Brushed or mirror finished
Door lock	Electronic Interlock
Glass Windows	502x502x5	650x650x5
	Double glazing windows with black backing finished frames
Germicidal Lamp	8W
Cleanliness Class	ISO 5 Class ( Better than 209E Class100)
Air Speed	0.45m/s±20%
Filter System	520x520x93	650x650x93
	Flume HEPA：99.99% 0.3um
Pressure Gauge	Dwyer 0-500Pa
Check point	SUS PAO and DOP check point
Power	220V 140W

Case Share:

Weigao Holding

Taiko Group
